CAURUS Hybrid system

Integrated supply air diffuser with thermal
building mass connection

In combination with the A11-S, SPECTRA M-S or VARICOOL TKM-S ceiling sails or the SOFTLINE WOOD high performance module, the CAURUS Hybrid system combines heating and cooling, supply air distribution and acoustic effectiveness. The system offers very high heating and cooling capacity, silent and draught-free fresh air supply and superior sound absorption values.

Based on the thermo-active building system principle, the climate ceiling system integrates the building mass into the room's overall thermal concept as an additional thermal storage mass. The building mass can absorb heat and release it again at a later time. This allows its storage capacity to be used specifically as part of the heating and cooling concept.

Thermal comfort according to EN ISO 7730, SIA 382/1
In combination with A11-S, SPECTRA M-S, VARICOOL TKM-S and SOFTLINE WOOD
Very high heating and cooling capacity
Superior sound absorption values (class A)
Building mass can be used as an additional thermal storage mass
Integrated cross-talk sound attenuation (option)
Low construction height
Sound power level Lw < 30 dB(A)
Silent and draught-free fresh air supply

System combinations

+ A11-S Radiant metal ceiling sail
+ SPECTRA M-S Radiant metal ceiling sail

+ VARICOOL TKM-S Radiant textile ceiling sail
+ SOFTLINE WOOD High performance module

Cooling capacity > 100 W/m² (8 K)
Heating capacity > 100 W/m² (15 K)
Sound absorption Class A
Carbon footprint < 50 kg CO₂/m²

Basis for assessment

Cooling capacity

The cooling capacity corresponds to the amount of energy per second removed from the room via heat radiation and convection. It is determined in accredited climate laboratories in accordance with SN EN 14240.

For comparison: the heat emitted by a person in an office via radiation and convection is approx. 70 – 80 W; the heat emitted by a laptop is approx. 20 – 50 W.

Heating capacity

The heating capacity corresponds to the energy per second added to the room via heat radiation and convection. It is determined in accredited climate laboratories in accordance with SN EN 14037.

For comparison: The heat output of a person in an office via radiation and convection is approx. 70 – 80 W, whilst that of a laptop is approx. 20 – 50 W.

Sound absorption

As the largest unobstructed surface in a room, the ceiling is particularly well suited to sound absorption. The sound absorption class is determined in accordance with EN ISO 11654, based on measurements carried out in accordance with EN ISO 354 in accredited laboratories.

It serves as a parameter for acoustic designers to calculate the effect of a product on a room’s reverberation time.

Carbon footprint

The carbon footprint describes the greenhouse gas emissions associated with a product. These emissions are expressed as CO₂ equivalents. The life cycle stages considered are specified in the respective Environmental Product Declaration and its defined system boundaries.

An Environmental Product Declaration (EPD) transparently presents various environmental impacts of a product based on a life cycle assessment. The calculation is carried out in accordance with the standards and methodological requirements specified in the EPD. Where stated, the EPD is verified by an independent third party.
